Starwatt Mini UPS Pro | Three Voltage Output 12V upto 3A, 9V upto 2A, 5V upto 3A | USB Powered Devices | 12 to 18 Hours Backup | 1 Year Warranty
₹8,299.00
Supports All Brands & Internet Service Providers WiFi Router | Modem | ONT | ONU. Also works with Amazon Alexa Smart Speakers | Raspberry Pi | Arduino | Intercom | Set-top Box | Smart Speakers | Biometric Attendance Machines | POS Machines | WiFi Cameras | Media Converters, etc. Please Self-Check the Compatibility before connecting the UPS.
- One Year Warranty
- COD Available
- 7 Days Replacement
- One Year Warranty
- COD Available
- 7 Days Replacement
Power Source / Input – Router’s Power Adaptor Input: 19V, 3.6A /- 5%
Number of Outputs – Three
Power Output – 5V, <2A /- 1% | 9V, <2A /- 1% | 12V, <2A /- 1%
Battery Capacity – 31200mAh | 140.55Wh | 12 x 2900 mAh
1.Switch off your Router Main Power Supply.
2. Disconnect your Router from Power Adapter.
3. Ensure that Router UPS Push Button switch is in OFF position (Red mark in pressed down position is ON; other way is OFF).
4. Connect Router Power Adapter to “IN” side of Router UPS.
5. Connect “OUT” Side of Router UPS with supplied Cable to your Router Power Input.
6. Switch on the Main power supply.
RED Light on Router UPS Indicates Router UPS is receiving Power from the Adaptor and Battery Charging.
BLUE Light on Router UPS Indicates Router UPS is receiving Input Power and Battery is fully charged.
Green Light on the Router UPS Indicates Router UPS is Not receiving Input Power and UPS mode is ON.
7. Switch on the Router UPS Push button switch. Now your router should be up.
1. Please check the power ratings of your Wi-Fi router/adapter (written on back of router/adapter) before ordering the compatible model. Router’s voltage must match with UPS voltage.
2. The Starwatt Wi-Fi Router Online UPS should be charged for 1 hour before first use.
3. Please check the power ratings of your Wi-Fi Router to order compatible model. Self-Check compatibility section can help to choose the right model.
4. Make sure to connect your adaptor to the input. Connecting the power source to the output jack can permanently damage the device and void warranty.
5. Keep the UPS away from the reach of children.
6. Compatible with all 12V, 9V, 5V, <2A powered Modem, Wi-Fi/ADSL routers. Wi-Fi routers, set top box, Alexa, CCTV, POS.
Description
Starwatt Mini UPS Pro saves your internet connection or any Device connected from disconnecting when there is a power failure.
It is designed to provide emergency power backup for 8 to 12 Hours to all kinds of DC power equipment such as WiFi Routers | Modem | ONT | ONU | Alexa | Raspberry Pi | Arduino | Intercom | Set-top Box | Smart Speakers | Media Converters | Biometric Attendance Machines | POS Machines | WiFi Cameras, etc.
Featuring an intelligent Battery Management System, this UPS charges itself when there is electricity, and in case of power failure, it seamlessly switches over to the battery mode instantly.
Specifications:
| Brand | STARWATT |
| Manufacturer | Starwatt Technologies Private Limited, Zirakpur Punjab, India |
| Model Series | Mini UPS Pro |
| Model Year | 2023 |
| UPS Dimensions | L 17.5 cm x W 10 cm x H 5 cm |
| LED indicator | Charging, UPS Running on Battery, Full Charged, Battery Level 25%, 50%, 75%, 100% |
| UPS Model | ROUP1295V2T |
| Number of Items | Mini UPS Pro (1), Bridge Cable (3), USB Bridge Cable (1), Power Adaptor (1), Connectors (3), User-Guide (1), Warranty Card (1) |
| Power Source / Input | 19V, 3.6A /- 1% |
| Power Output | 5V, <2A /- 1% | 9V, <2A /- 1% | 12V, <2A /- 1% |
| Number of Output | Three |
| UPS Switching Type | Zero Lag Switching |
| Battery Backup Time | 8 to 12 Hours |
| Batteries Included | Yes – Contained inside UPS |
| Batteries Type | High Energy Density Lithium-ion batteries |
| Battery Capacity | 31200mAh | 131.04 Wh | 12 x 2600 mAh |
| Battery Protection | Battery Management System Overcharge and Deep Discharge Protection |
| Cable Length | 30 cm |
| Connector Type | DC Jack IN: 5.5*2.1mm, OUT: 5.5*2.1mm, Additional Connectors : 5.5*2.1mm to 5.5*2.5mm (1), 5.5*2.1mm to 4.0*1.7mm (1), 5.5*2.1mm to 3.5*1.35mm (1) |
| Material | Polycarbonate |
| Wall Mount | No |
| Country of Origin | India |
| Item Weight | 1500 Grams |
24×7 Operation
- Up to 6-8 hours Backup – 15600mAh Li-Ion Battery with Intelligent Battery Management System for Over-Charge and Low Battery Deep Discharge Protection.
Zero-Lag Switching
- Allows your Router/Modem to seamlessly continue functioning during power outages with no downtime.
Intelligent Charging
- Comes with a True 12V 3.5A Adaptor for Fast charging and Powering Devices simultaneously.
- 3X Battery Life with Optimized CC-CV Charging algorithm ensures that the internal battery of Router Online UPS is charged safely and provide a much longer battery life.
Portable & Light Weight
- Quick installation with Plug and Play Design.
- Comes with LED Indicator for Charging, UPS Running on Battery, Fully Charged. Easy to Operate | Wall Mount design | Removable 30cm Bridge Cable.
Supported Devices
- Compatible with wide range of devices: WiFi Routers, Modems, ONT, ONU, WiFi Cameras, CCTV Cameras. Media Converters, USB Powered Devices, Smart Speakers etc.
- Supports All Type of 12V DC Devices from 12V – 0.5A, 12V – 1A, 12V – 1.5A, 12V – 2A, 12V 2.5A, 12V 3A | 9V – 0.5A, 9V – 1A, 9V – 1.5A, 9V – 2A | 5V – 0.5A, 5V – 1A, 5V – 1.5A, 5V – 2A.
Compatibility Check
Frequently Asked Questions:
Router Online UPS has an intelligent battery management system that automatically charges the battery when the power is available and seamlessly switches to battery mode during power cuts.
Battery will only charge when UPS is connected to Adaptor with the power switch in the ON position.
Yes, connectors for thin pin routers are included in the package.
Q: What’s the backup time? How can I decide which model is suitable for my device?
A: Different make/models of routers, consume different amounts of current. Hence, backup time will depend on the make/model of the router from 3 to 6 hours.
You can choose the most suitable UPS for your Router from the list of the UPSs by getting the below-mentioned information:
1. What is the device you plan to use?
2. What is the working voltage and currently mentioned on the Adaptor or Router?
3. What is your expected backup time?
Q: How can I maintain the device’s lifetime?
A: When stored, the ups will self-discharge at a rate that is greatly affected by the ambient temperature. It should therefore be fully charged before being put into storage and if it is to be stored for a long period, it should be recharged periodically to prevent it from losing its original capacity.
If the UPS is not used for a long time, it is suggested to charge it once every 3~5months
Q: Do you have any other models?
A: Yes, we have various models with different voltage configurations, you can contact us at +91-8971090763 contact for more details.
Q: How long does the Router Online UPS provide power backup?
A: Up to 6 hours and depends on your make/model as power consumption varies with different OEMs.
Q: How do I know if Router Online UPS will work with my Wi-Fi Router? Is there a compatibility list?
A: Starwatt Wi-Fi Router Online UPS has a range of models that supports 5V, 9V, 12V powered Wi-Fi, Wi-Fi/ADSL Router. We also provide dual and triple output devices. Please ensure power compatibility by looking at the specification sticker on the backside of the Router/Modem and power adaptor before you place the order.
Q: How do I install Router Online UPS?
A: Router Online UPS is designed for DIY (Do It Yourself). It’s really simple to install – The installation guide in the packaging box will help you install Router Online UPS in less than 30 seconds.
Q: How long does it take to install Router Online UPS to my Wi-Fi Router?
A: 30 Seconds only.
Q: Does it work with ADSL/Wi-Fi Routers?
A: Yes. Please ensure to buy/use the model with appropriate power ratings.
Q: Will my Wi-Fi Router be affected anyway?
A: No, Router Online UPS is carefully designed with several safety protection circuits and a battery management system to ensure the safety of your Wi-Fi Router.
Q: I have an ADSL Router (Modem) and a separate Wi-Fi Router, Can Router Online UPS provide power backup to both?
A: Router Online UPS is primarily designed for a single device. However, you can use a splitter cable if the combined power ratings of your Modem and Router are less than the Router Online UPS specifications.
Q: Does Router Online UPS come with a warranty?
A: Yes, Router Online UPS comes with 1 Year warranty.
Q: Can I connect Router Online UPS with any 9V device?
A: Yes. Please check the power ratings of the Wi-Fi router before connecting to the Router Online UPS. If the Rater operational voltage is 9V, then it can be used to provide power backup to any 9V router.
Q: Can I use this outdoor?
A: No. The current version of Router Online UPS is designed for Indoor use.
